Back to: 2-Way Pallet Trucks

Pallet Trucks

Powder Coated Manual Jack

View & Buy Models

Heavy Duty Pallet Truck
2-Way Jack with Manual Pump
1 Year Warranty


Model Number	QTG-NBL-005	QTG-NBL-006	QTG-NBL-007	QTG-NBL-008	QTG-NBL-009	QTG-NBL-010	QTG-NBL-011
Capacity (kg)	2500	2500	2500	2500	2500	2500	3000
Fork Span (mm)	520	520	685	450	520	685	520
Fork Length (mm)	900	1000	1000	1150	1150	1150	1150
Fork Width (mm)	160	160	160	160	160	160	160
Lift Height (mm)	75 - 190	75 - 190	75 - 190	75 - 190	75 - 190	75 - 190	75 - 190
	$595.00 Add to Cart	$595.00 Add to Cart	$595.00 Add to Cart	$595.00 Add to Cart	$595.00 Add to Cart	$595.00 Add to Cart	$695.00 Add to Cart
Specification PDF	Download	Download	Download	Download	Download	Download	Download

This pallet truck can access most standard pallets, but with blue CHEP pallets, it can only lift them from the two sides with larger gaps. These trucks are designed for rigorous every-day use pushing and pulling pallets in a wide range of industries. They easily lift pallets with their tiller-pump and release trigger.

Features & Benefits

Manually propelled
Hand pump raise/lower
Powder-coated finish
Excellent control of lowering speed allows fragile or loose items to be lowered with ease
Pressure relief overload valve prevents damage of the pallet truck if it is loaded above its maximum capacity
Zinc plated hydraulic pump means it will always run smoothly, even if the pump gets a little wet
Polyurethane (PU) wheels and rollers are durable, non-marking and quiet
Chrome bearing bushes and joints ensure quiet, smooth running and long service life
All pivot points are greased to provide excellent manoeuvrability and effortless steering
Strong warp-resistant steel construction
Ergonomic tiller with comfortable grip ensures operators can use the pallet truck for long periods of time without tiring
Some Assembly Required
