Roller Conveyor (250mm)
Gravity Roller Conveyor
- 50mm diameter Rollers with Spring loaded Shaft
- Robust Double Ball Bearing Zinc Plated Steel Rollers
- 1 Year Warranty
Gravity Roller Conveyor
|
|
|
|
|
|
|
|
|
|
Model Number |
CRZ-AST-001 |
CRZ-AST-002 |
CRZ-AST-003 |
CRZ-AST-004 |
CRZ-AST-005 |
CRZ-AST-006 |
CRZ-AST-007 |
CRZ-AST-008 |
CRZ-AST-009 |
Capacity per metre (kg) |
60 |
55 |
50 |
60 |
55 |
50 |
450 |
55 |
50 |
Pitch (mm) |
75 |
112.5 |
150 |
75 |
112.5 |
150 |
75 |
112.5 |
150 |
Overall Length (mm) |
1200 |
1200 |
1200 |
2400 |
2400 |
2400 |
3000 |
3000 |
3000 |
Overall Width (mm) |
250 |
250 |
250 |
250 |
250 |
250 |
250 |
250 |
250 |
|
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
Enquire For Price Add to Quote |
|
Specification PDF |
These 250mm wide Gravity roller conveyors are ideal for conveying boxes, cartons and containers etc from one point to another. They are ideal in warehousing and dispatch areas or can be used in a double row placed directly on the floor for conveying pallets. A high quality product that ease the daily load on workers backs & Limbs.
The pre-punched Zinc plated side frames allow for adjustment in the conveyor spacing if needed.
The Zinc Plated steel rollers are included with the frame
