Stainless Steel Hydraulic Lift
Hydraulic Lifter Stainless
- Grade 304 stainless, good for corrosive applications.
- Stable chassis with 2 frame rollers and 2 steering rollers.
- Simple and Easy Operation
- 1 Year Warranty
Hydraulic Lifter Stainless
|
|
Model Number |
LUZ-NUL-003 |
Capacity |
400 |
Lowered Height (mm) |
85 |
Lift Height (mm) |
1500 |
Free Lift Height (mm) |
1500 |
Overall Height (mm) |
1735 |
Overall Width (mm) |
590 |
Overall Length (mm) |
1070 |
Drive Type |
Manual |
Lift Type |
Manual |
Fork Spread (mm) |
210 to 545 |
Fork Length (mm) |
650 |
Fork Size (mm) |
100x50 |
Load Centre (mm) |
300 |
Outrigger Height (mm) |
75 |
Outrigger Length (mm) |
600 |
Width in Between Outriggers (mm) |
375 |
Front Wheel Diameter (mm) |
75 |
Rear Wheel Diameter (mm) |
125 |
Unit Weight (kg) |
83 |
|
Enquire For Price Add to Quote |
|
Specification PDF |
The Stainless Steel Hydraulic Lifter is a robust and easy to use machine designed for precise lifting and positioning applications. Made from grade 304 stainless steel, it offers exceptional resistance to corrosion, ensuring longevity and reliability even in harsh environments. Ideal for use in manufacturing and pharmaceutical operations, this hydraulic lifter utilizes a manual hydraulic pump for controlled lifting movements. Its durable construction provides superior strength and stability, making it suitable for a wide range of applications requiring heavy lifting or positioning tasks. With easy maintenance, this lifter is a trusted solution for improving efficiency and safety in lifting operations.
